TRS 7

TRS 7 profile is designed for commercial and industrial roofing. The profile is suitable for low pitch roofing as well as curved roofing. Commercial and industrial roofing G550 grade steel with minimum 0.55 BMT gives more resilience to damage. Available in Duralume, Sandstone Grey, Gull Grey, and Titania White.

SPECIFICATION AT A GLANCE

GENERAL

  • Minimum Roof Pitch
  • Effective Cover
  • Overall Width
  • 3 Degree
  • 890 mm
  • 934 mm
  • SPANS
  • End Span 0.40/0.55 BMT
  • Internal Span G550/0.55 BMT
  • 1400 mm/1100 mm
  • 1700 mm/2700 mm
ROOF FIXINGS

TIMBER

  • Class 4 14 x 75mm with neo washer and embossed washer, approved profile’s metal washer and EDDM washer
  • STEEL
  • Steel: 12 x 65mm with neo washer and embossed washer, approved profile’s metal washer and EDDM washer
  • ACCESSORIES
  • Flashing up to 8 meters, Pipe flashings, Rivets, Underlays, Netting and Sealants, Translucent roofing to match

*Contact The Roofing Store for further information on specific design
